LINEVO SANITARY GEL & JELLY LAB // SUS304/316L CIP & MULTI-LANE SYSTEMS

Automatic Jelly, Energy Gel, Cup Seal & Gummy Packaging Machines

LINEVO 4–16 lane heated-piston konjac & energy gel stick machines, SUS316L CIP jelly cup sealers, LV-160 spout fillers & LV-210 multipack lines.

15,000+ m² Foshan PlantSince 2013 OEM Builder50+ Patents Dosing & CIP5,000+ Lines Worldwide
02 // CLOSED-LOOP SANITARY SEAL INTEGRITY

3-Node Synergy: Anti-Drip Piston Dosing ↔ Multi-Stage Heat Seal ↔ Clean Cut

Leaking gel sticks and popped jelly cup lids rarely start at the heater—they start when hot hydrocolloid syrup strings across the seal flange. LINEVO synchronizes dosing retraction, thermal dwell, and blade cutoff as one closed loop.

Hot-Fill & Film Specs
NODE 01 // RHEOLOGY & DOSING

Hot-Fill & Anti-Drip Piston Dosing

Double-walled electric jacketed hoppers with mixing paddles prevent konjac/carrageenan pre-gelling, while independent rotary-valve pistons and AirTAC suck-back nozzles retract syrup cleanly after every stroke.

Zero Post-Stroke Stringing
NODE 02 // HERMETIC FUSION

Multi-Stage Heat Seal Consolidation

Because suck-back cutoffs keep cross-seal jaws and cup flanges free of hydrocolloid film, PID-regulated seal bars fuse leak-free easy-peel or retort-grade foil seams across all 4–16 lanes simultaneously.

Dry Seal-Zone Interlock
NODE 03 // SEPARATION & QA

Clean Cut, Tear-Notch & Discharge

Precision rotary slitting blades, easy-tear notch dies, and cup waste-matrix rewinds discharge finished sticks or cups smoothly onto pasteurization/cooling conveyors prior to LV-210 multipacking.

Compression Burst Verified
SUS304 / SUS316L Mirror-Polished Contact + Clean-in-Place (CIP) FlushingCitric/malic acid sports gels and sticky pectin syrups flush cleanly between flavor runs without multi-hour tube disassembly.
Inspect Leak-Test Checklist
03 // 8-STAGE SANITARY SAMPLE-TO-FAT PROJECT PATH

Two Buyer Decision Gates: Sample Test Before Build & Video FAT Before Balance

Every multi-lane rotary piston manifold, jacketed hopper, and CIP cup sealer follows an 8-stage engineering path at our 15,000+ m² Foshan factory.

Inspect Factory Credentials
  1. STAGE 01

    Gel Rheology & Pack Brief

    Share gel viscosity (cP), dosing temperature (°C), fruit/chia particle mm, and stick, cup, or pouch dimensions.

  2. STAGE 02DECISION GATE

    Foshan Hot-Fill Sample Test

    BUYER DECISION GATE: Ship gel formulation and barrier film/cups to Foshan to verify suck-back anti-drip cutoff and peel/burst strength.

  3. STAGE 03

    Lane & Parent-Film Sizing

    Select exact 4–16 lane pitch (420 / 500 / 700 / 980 mm web) or cup cavity count matched to shift OEE targets.

  4. STAGE 04

    2D Cleanroom & CIP CAD

    Engineers map cooking-kettle feed height, CIP return piping, cooling tunnel transfer, and secondary multipacker footprint.

  5. STAGE 05

    Itemized Written Quotation BOM

    Receive written SUS304/316L contact specs and Siemens, OMRON, Delta, and AirTAC cabinet BOM before ordering.

  6. STAGE 06

    Sanitary Machining & Assembly

    Mirror-polished manifolds, jacketed hoppers, and sealing frames are built inside LINEVO's 15,000+ m² Foshan plant.

  7. STAGE 07DECISION GATE

    Pre-Balance Video FAT & Burst Check

    BUYER DECISION GATE: Inspect full-speed hot/viscous dosing video, lane weight uniformity, and compression leak tests before final balance.

  8. STAGE 08

    Export Crating & Startup Recipes

    Shipped in fumigation-free crates with FKM/silicone sanitary gaskets, pre-saved HMI lane recipes, and remote/on-site support.

LINEVO 15000 square meter sanitary multi-lane stick, cup sealer, and pouch machine assembly bays in Foshan
Foshan Sanitary Equipment Assembly Bays15,000+ m² workshop building 4–16 lane gel stick lines, CIP cup sealers, and LV-210 baggers.
LINEVO Foshan sample testing workbench verifying hot-fill stick seal burst pressure, anti-drip cut-off, and cup lid peel force
Hot-Fill & Seal-Burst Verification LabPre-shipment lane weight uniformity, suck-back anti-drip checks, and compression leak testing.
04 // SANITARY ELECTRICAL & ANTI-DRIP PNEUMATIC BOM

Verified 4-Brand Control & Pneumatic Subsystems

Multi-lane rotary piston dosing, suck-back anti-drip cutoff, and heated hopper control depend on serviceable international PLC, encoder, touchscreen/VFD, and pneumatic hardware.

SUS304 / SUS316L + 4-BRAND BOM
CONTROL CABINET // 01Siemens

PLC Motion & Sequence Controller

Main programmable logic controller coordinating multi-lane rotary piston dosing, film/cup indexing, jacket heating, and sealing interlocks.

TIMING & DC BUS // 02OMRON

Rotary Encoder, Control Relays & 24V Switching Power Supply

Phase-angle timing feedback, cabinet switching relays, and regulated 24V DC power supply across multi-lane stick, sachet, and cup stations.

OPERATOR & DRIVE // 03Delta Electronics

HMI Color Touchscreen & Variable Frequency Drive (VFD)

Multi-recipe touchscreen terminal storing lane dose/temperature profiles and inverter motor speed control for main drives and conveyors.

ANTI-DRIP PNEUMATICS // 04AirTAC

Pneumatic Cylinders, Solenoid Valves, Vacuum Gauge & FRL Unit

Suck-back anti-drip nozzle actuators, cross-sealing cylinders, manifold valves, pouch-opening vacuum gauge, and air preparation unit.

Representative electrical, sensing, and pneumatic hardware fitted on LINEVO packaging configurations; exact part series or project-specified alternatives are itemized in your written quotation BOM.

05 // INTERACTIVE SANITARY LINE CONFIGURATOR

Match Dosing Pump & Seal Geometry to Your Gel Formulation

Select your primary jelly, sports gel, cup, or gummy format below to inspect recommended hot-fill and multi-lane parameters for your Foshan engineering brief.

ENGINEERING BRIEF // 01KONJAC-STICK-PACK

Multi-Lane Konjac, Collagen & Energy Gel Stick Line

LINEVO 4-to-16 lane jacketed-hopper rotary-piston stick-pack and 4-side-seal sachet machines (LV-600X, LV-500SY/700SY/980SY, dession-117/118/231).

Recommended FAT Inputs to Share:
  • Gel formulation (konjac, carrageenan, collagen, or maltodextrin sports gel) & cP viscosity
  • Hot-fill dosing temperature (°C) + jacketed agitator hopper requirement
  • Stick finished width × length (mm), fill volume (1–30 ml), and easy-tear notch shape
  • Target sticks/min (4 to 16 lanes) and plant supply (220V / 380V / 480V 50/60Hz)
06 // SYSTEM ARCHITECTURES & TECHNICAL HUBS

Core Jelly Categories & Sanitary Specifications

Explore complete engineering sheets covering 4–16 lane stick machines, hot-fill pump & barrier film specs, CIP cup sealers, and turnkey cooking-to-multipack lines.

07 // SIZING CALCULATORS & BUYER GUIDES

Multi-Lane Output Math, Film Width Charts & Leak-Test Checklists

Size lane counts against shift targets, compute exact parent-film roll widths for stick and 4-side-seal sachets, and review hot-fill FAT acceptance checklists.

08 // PRE-FAT TECHNICAL FAQ

Frequently Asked Questions

Direct engineering answers on pneumatic suck-back anti-drip nozzles, hot-fill konjac & fruit-inclusion dosing, 4–16 lane scaling, and secondary gummy/jelly multipacking.

Have Gel Formulations, Cups, or Stick Film Samples?

Send fill ml/g, dosing temperature (°C), and shift target to schedule a Foshan rotary-piston and seal-burst evaluation.

How do LINEVO multi-lane jelly stick machines prevent viscous syrup from dripping into the seal zone?

LINEVO's dession-117, dession-118, and dession-231 multi-lane gel machines pair independent rotary-valve piston pumps with pneumatic suck-back anti-dripping shut-off nozzles that retract the liquid meniscus cleanly at the end of every stroke.

Can LINEVO run hot-fill konjac jellies and gels containing chia seeds or fruit pulp?

Yes. Double-walled jacketed agitated hoppers keep hot-fill konjac and carrageenan sols at uniform temperature, while the dession-128 Particulate Gel Pouch Machine and dession-185 CIP Cup Sealer handle suspended seeds, pulp, and fruit cubes.

What lane counts and speeds do LINEVO multi-lane stick and sachet machines cover?

Model LV-600X runs 4–16 back-seal stick lanes (1–30 ml, max 420 mm web), while the LV-500SY / LV-700SY / LV-980SY 4-side-seal sachet series scales across 2–4, 3–10, and 4–16 lanes at 20–40 cuts/min (up to 640 sachets/min gross) for 5–100 ml fills.

Does LINEVO supply secondary multipack baggers for gummies and cooled mini-jelly cups or sticks?

Yes. LINEVO's dession-49 / dession-51 Anti-Sticking Multihead Weigher VFFS systems (30–70 bags/min, ±0.1–1.5 g) and Model LV-210 Premade Zipper Stand-Up Bag Machine (20–70 bags/min, W 90–210 × L 110–330 mm) automate retail assortment bags.
